Saturday, December 26, 2009

Wings on its Fingers

It is of course an easy matter to get excited about the latest fossil find. A new species that supplies a previously-missing piece to the puzzle of where to fit what into the scheme of things deserves the attention that it receives in scientific circles and beyond. By way of contrast, other fossil specimens which might have been discovered decades ago, and which represent now-familiar fossil animals, perhaps run the risk of losing their edge through simple familiarity.


Recently I obtained (via the Internet, naturally!) a museum-quality cast of one of the best-known of all fossil pterosaur specimens (the original fossil, above, is here shown about life-size). This is the species Pterodactylus kochi, which was no larger than a common garden bird of today. The slender toothed skull is just 73mm (almost 3 inches) long, and in life the delicate animal would have had a wing span of some 40cm (16 inches). The fossil is one of the best-preserved of its kind; not only every bone can clearly be seen, but the fleshy outline of the animal, and even the indication of the wing membranes, have been preserved.


The extended fourth digit which formed the leading edge of the wing ('pterodactyl' means 'wing-finger') is perfectly articulated in the fossil, and even the sclerotic ring (the tiny circle of bony plates that supported the eyeball, below) is clearly visible. In life, the animal would have been covered with a thin layer of integuments similar to hairs in structure (my life reconstruction drawing, above), and the tiny teeth would have grasped and held insects on the wing.

Since dragonflies (below) have been found in the same fossil beds, it is reasonable to speculate that these would have been on the menu of this small pterodactyl. This pterosaur fossil comes from the famed deposits of Solnhofen limestone in Bavaria: the same fossil site where Archaeopteryx was discovered. Together with the small dinosaur Compsognathus and other species of pterosaurs, these creatures formed a community of Jurassic animals living in what was then an archipelago of islands lying in warm tropic seas.

It was among these islands that the pterosaur which my fossil cast portrays hunted and caught insects on the wing, living out its life until - for whatever reason - it died. The small body sank into the sheltered waters of a coastal lagoon, where, in the layer of oxygen-starved water lying in the deepest part of the lagoon, the body was hardly touched by the processes of decay - or by the actions of scavenging crustaceans - before being covered by silt. The covering of finely-compacted sediments provided further ideal conditions for fossilization to take place, and for the little pterosaur to begin its one hundred and fifty million year-long journey to our own time.
Hawkwood

Thursday, November 26, 2009

Death in Montana

One of the most justly-famous fossil finds in dinosaur studies was the group unearthed in 1964 in Montana by the late Professor John Ostrom. The group consisted of the remains of the herbivore Tenontosaurus, together with between three to four individuals of a newly-discovered carnivorous dinosaur that was given the name of Deinonychus antirrhopus (literally: 'Terrible-claw/counterbalance'). What so excited the world of palaeontology was that the group appeared to show, not merely evidence of active predation, but a coordinated effort by predators to bring down a herbivore. In short: the Deinonychus were co-operating as a pack to hunt and kill the much larger Tenontosaurus.


Not surprisingly, this find was gratefully seized upon by palaeoartists as a worthy subject; not just because of its significance, but because of the possibilities which it offered for portraying some real down-and-dirty dinosaur action, while remaining faithful to the fossil material. When I came to produce my own version (above), I decided to use the tails of the animals as a compositional device to convey the drama of the kill. From their fossil remains, we know that Deinonychus had relatively inflexible tails, presumably to act as an effective counterbalancing rudder (hence 'antirrhopus') when running and turning. And for a herbivore of its type, Tenontosaurus had an unusually long tail.


My first rough pencil sketch (above) utilised these tails as a device for focusing the action towards the point of attack. This sort of worked, but with the predators coming from all sides, it did not completely convey the effect that I was after: that the Tenontosaurus was literally being knocked off balance by the ferocity of the attack. My second more detailed pencil drawing (below) placed the two Deinonychus at the hindquarters of their prey, which gave all four tails - both of predators and of prey - a uniform thrust, as if driven by an unstoppable force of fate. This seemed to work more effectively, and I scanned in the drawing and continued to work on it digitally, painting in the lighting effects and colors with digital brushes.


The deposits of the find indicate that the encounter took place on the bed of a dried-out river or delta, probably close enough to the undercut bank for the earth to have collapsed and hastened the animals' burial. I freely admit that using back-lit dust is a favorite device of mine for injecting atmosphere into such a scene, so this setting was from my point of view ideal. By altering the drawing so that the tenontosaur's forelegs were folded away out of balance, I now had the effect of it being knocked off its feet by the force of the Deinonychus impacting its body. The second Deinonychus was now also falling (the detail, below), and clearly in danger of having its skull crushed beneath its prey, which conveyed the idea that predators as well could be - and often are - the victims of their own attack. Active hunting can be a dangerous pursuit.


And so, in apparent faithfulness to the fossil material, I (and other paleoartists) dutifully portrayed one Tenontosaurus being attacked by three (or four) Deinonychus, with the clear implication that the raptors were coordinating their attack with each other. Thus portrayed (and whomever paints it), it has become one of the iconic images of paleo art; and the pack behaviour of raptors - and the implied intelligence required - was cheerfully made further use of in the Jurassic Park scripts. But is this really the way things were on that dusty Montana river bed some one hundred and thirteen million years ago? Even given the specifics of the fossil evidence, how can we be so sure?


It is both illuminating and rather sobering to look at Ostrom's original map of the site. This scattered tangle of fossil bones is what Ostrom actually had to work with. We know for certain that at least three Deinonychus and one Tenontosaurus died here. But that is all. There can be no way of knowing whether or not the raptors truly were acting co-operatively, or whether they were there just joining in an opportunistic meal when death, perhaps in the form of the collapsed river bank, overtook them. It is even possible, and has been *suggested, that a scavenging frenzy took place, in which other Deinonychus turned upon their own kind for a cannibalistic feast. But a truly coordinated pack attack, as practiced by wolves, wild dogs, and other such carnivorous mammals, is assumption.

And even if Deinonychus was intelligent as predatory dinosaurs go, this is still a long way from the intelligence and social interaction of mammals. And the fossils record only the dead. How many other animals were originally at the scene which simply lived and walked away? My painting depicts a lone tenontosaur, but there might have been several of these herbivores present, with only one falling victim, both to the raptors and to the processes of fossilization. Over the border in Wyoming another such site has been found. But this second site reveals the remains of no less than six tenontosaurs - and only one solitary Deinonychus. The scarily social and rationalising raptors of Jurassic Park were, after all, movie dinosaurs. Palaeontology must cope with situations which, as often as not, offer more than one viable scenario.
Hawkwood


Sources:
Ostrom, John H.: 'Osteology of Deinonychus antirrhopus, an unusual theropod dinosaur from the Lower Cretaceous of Montana'. New Haven: Peabody Museum of Natural History, Yale University, 1969. Series: Yale University. Peabody Museum of Natural History. Bulletin 30.
Parsons, William L., and Parsons, Kristen M.: 'Further descriptions of the osteology of Deinonychus antirrhopus (Saurischia, Theropoda)'. Bulletin of the Buffalo Society of Natural Sciences, Volume 38, 2009.
*Roach, Brian T., and Brinkman, Daniel L.: 'A Reevaluation of Cooperative Pack Hunting and Gregariousness in Deinonychus antirrhopus and Other Nonavian Theropod Dinosaurs'. Bulletin of the Peabody Museum of Natural History 48(1):103–138, April 2007.

Sunday, November 22, 2009

The Eye of a Raptor

This is the eye of a living raptor. But before anyone starts wondering whether some enterprising scientist has succeeded in turning a fictional Jurassic Park into reality, we need to define our terms. Raptors, as the word is understood and used in dictionary terms, are birds of prey. These can include the hawk whose eye is pictured here, as well as such birds as falcons, owls and eagles.


But since the release of the film Jurassic Park (below), the word raptor has become synonymous with a specific kind of dinosaur: middling-sized, it's true, but - at least as far as raptors are portrayed in Spielberg's films - ruthlessly predatory, alarmingly intelligent, and given to teaming up with others of their kind to hone their social hunting skills to a shocking efficiency.



And these dinosaur raptors had the armaments necessary to do this. The most obvious characteristic which such raptors had in common was the specialized second digit on their hind legs, which had evolved into a large killing claw (below). Raptors therefore used their third and fourth digits for walking and running, with the killing claw held upwards; it was simply too big to be functional for locomotion.


The word raptor comes from the Latin, meaning a ravisher or plunderer, and several dinosaurs carry the term in their name - Velociraptor, Utahraptor and Bambiraptor, to name just three (see the comparative sizes of *five of them, below) - although the name of one of the most typical 'raptors' of them all - Deinonychus - does not refer to the term.


Exactly how much we currently know and understand about these raptorial dinosaurs - and the other dinosaurs and animals which shared their world - is the subject of this weblog. Did raptors really hunt in packs, as portrayed in Spielberg's films? How can we know one way or the other? Indeed, were the 'velociraptors' in Jurassic Park really velociraptors at all? I have drawn and painted many life reconstructions of dinosaurs and other Mesozoic fauna, both professionally and for my own pleasure, and will be using these and related material to illustrate this weblog. And if a little philosophy creeps in along the way, well; what could be more viscerally existential than the thought of a real raptor chomping at your heels?
Hawkwood


*From left to right: Bambiraptor, Velociraptor, Deinonychus, Utahraptor, Megaraptor

Friday, November 20, 2009

Patience please!



The raptors are currently being fed. As soon as they are through with their meal, they will appear on this weblog, and those patient readers with a stout heart and a steady nerve are welcome to check back later to meet them.
